Lu Yi brand wood oil rod production process Introduction

Company Profile:

Zhucheng Aetna Machinery Co., Ltd. specializes in producing all kinds of classes I, II, pressure vessels, is the largest and most professional manufacturer, is the design, manufacture, service, technical advice as one of the new modern enterprises. Main products: wood preservative cans, wood stain cans, wood cooking pot, a modified tank timber, wood skim tanks, high pressure vacuum impregnation tank timber, timber full cell dipping tanks, tank fire wood, wood retort, wood oil tank lever, railway sleepers cans, charring wood stove, wood stove depth carbonized wood vacuum drying equipment and other equipment. The company produces timber equipment, exported to Southeast Asia, Europe and Africa, more than 30 foreign countries and the domestic market. Woodworking equipment Description: Tel: 18953613205

Operation process:

Operating procedures: Before vacuum - join creosote - Boost - packing impregnated - relief - discharged creosote - vacuum - recovery atmosphere - Remove the timber door open cans

Vacuum pressure method is wooden poles, railway sleepers deal with the most important and most effective method of industrial processes. The timber into the tank, and then evacuated and high pressure injection of a process creosote inside the timber. Lu Yi licensing high-pressure timber oil bar automatic vacuum infusion equipment industry reached the advanced level, is the preferred brand manufacturers.

Steps:

1, before vacuum: preservative oil before adding to the tank evacuated aimed evacuating air from the wood cells, corrosion resistance of the oil into the timber interior will be reduced, in order to facilitate better creosote impregnated wood. Vacuum level is generally between 79.8-90kPa, hold time according to the product corrosion requirements.

2, plus creosote: while maintaining the vacuum, the vertical heat storage tank corrosion oil (claim 70-80 ℃) was added through the automatic valve to corrosion tank, to ensure that the air is trapped in the same situation of the timber cells. Tank level gauge a set of design and corrosion fill the oil tank corrosion, the control system automatically stops to refuel.

3, compression packing: antiseptic oil reached the level, turn the pressure pump start pressure. Pressure is raised to between 1.0-1.4MPa, and then holding the pressure to a predetermined time.

4, the pressure relief discharge creosote: After holding pressure return lines open automatic valve, corrosion oil tank automatic return to the tank, after the flow to the lower level gauge, the valve is closed to stop the oil return.

5, after evacuation: after corrosion tank oil return, open the vacuum system for secondary vacuum, the purpose of the luminal surface of the wood cells is withdrawn excess preservative oil, in order to reduce the dripping phenomena when the tank.

6, the tank: After restoring the atmosphere, the tank door opens, you can start the hoist out of wood.

1, the tank door openers:
Open the door open electrical automatic and manual mode, turn the hand wheel to achieve the door open or closed tank doors, a single person can easily complete the steps switch doors. This design is the most advanced way to open the door and philosophy. Never deformation, the use of safe, efficient, simple, efficient and worry. Normally switch tank door during a power outage.

2 cans door seals: inflatable tank door flange silicone seals, seal work automatically inflated by compressed air tank as long as there is pressure tank door will not leak out, and the greater the pressure seal better. When the door seal off the tank vent pressure, seals automatically return flange seal tank, seals do not wear, more convenient to use, easy to maintain, sealing effect is significantly better than the other way, seal life of more than 1 year.

3, double tank door safety interlock devices: dual tank door safety interlock to prevent pressure equipment work, worker error caused the door to open cans unsafe incidents. Completely solved due to the misuse of workers and other reasons potential safety problems. The device is designed two sets of safety door interlock device in the tank, Detailed follows:

(1), pressure automatic safety interlock devices: pressure in the tank at the top of the door to set an automatic interlock when the tank pressure reaches 0.01mpa, pressure safety interlock automatically suspended float tank door locked. As long as the tank pressure tank will not be able to open the door, to prevent safety hazards caused by misuse of workers.

(2), manual safety interlock devices: Only when working close manual valves chain, pressurized tank to heat up the boost, otherwise unable to form a pressure tank. When the chain must be opened manually open the door, otherwise we can not open the tank door. Make sure the tank door only state in the absence of pressure to open the tank door, as long as the tank pressure, even if the workers can not open cans misuse door, completely solve the security risks caused by the misuse of workers.

4, level control: Using magnetic level gauge, when the tank preservative added to the specified location, close the valve to stop preservatives enter.

5, vacuum control: After setting a vacuum table, vacuum reaches a predetermined value, the shut-off valve to stop the vacuum.

6, pressure control: tank set up two pressure gauges, pressure tank through a valve control, the pressure reaches a predetermined value after the shut-off valve to stop the boost and keep the pressure of time after a certain relief. Design two flanges open valve, the valve automatically after reaching the design pressure is on, make sure the tank safety.

7, the control system: according to customer needs has a computer automatic control, semi-automatic computer control, electrical semi-automatic control, manual control, reduce labor intensity and improve product quality and efficiency.

7, the tank loading: two rail tank, using the 18th rail steel, tank timber materials bearing type fast car, for a major, long life, safe and convenient.

VI. Production standards and specifications

According to national standards GB150-2001 and TSG R0004-2009 "Safety Technology Supervision fixed pressure vessel", JB / T4731-2005 "steel horizontal container", JB / T4730-2005, JB / T4709-2000, JB / T4711 -2003 design (design Institute issued a formal blueprint: category, age, degree of harm, corrosion allowance, pressure, temperature, medium, weld factor, nozzle orientation, technical requirements, etc.), manufacturing (according to the requirements of the drawings, each inspection, testing, record on file, supervisory inspection certificate issued by the local Bureau of Technical Supervision, sequestration).

Seven technical information provided by the supplier

1, the device is equipped with the National Pressure Vessel Safety Supervision Organization (Supervision Bureau) issued

"The pressure vessel products quality certificate"

"Product certification"

"Pressure Vessel Safety Performance Products Inspection Certificate"

"Factory supervisory inspection mark nameplate"

"Device builts" each.

Eight, after-sales service:

Service: The company sent a technician to the purchaser to guide the installation, commissioning, and training equipment operators

When we received the service call, day or night, to ensure that arrive within 48 hours.
